ShowNet

Topology

OpenFlow Usage

• Security (Traffic redirection)
• Booth drop
• Cache hookup
• OpenFlow 1.3.1 interoperability, providing a connectivity for a ShowNet Access Corner at POD 6.

Network Protection

	[2013-06-13_0066] A display at the NICT booth.
	[2013-06-13_0067] Zoom in. Blue: TCP_SYN, Yellow: TCP_SYN_ACK, Green: TCP_ACK, Pink: TCP_FIN, Cobalt: TCP_RST, Vermilion: TCP_PUSH, Pale Blue: TCP_OTHER, Red: UDP and White: ICMP.
	[2013-06-13_0068]

Exhibits in NOC

	[2013-06-13_0036] Facility related products.
	[2013-06-14_0120] Tools.
	[2013-06-14_0138] A printer.
	[2013-06-14_0137] Click here to enlarge (204KB).
	[2013-06-14_0202] A NOC member list, and Takahashi-san, Founder of Interop Tokyo.

Network Service

	[2013-06-14_0142]
	[2013-06-14_0106]
	[2013-06-14_0189] An example of APs.
	[2013-06-13_0028] ShowNet Access Corner, behind PODs

20th Interop Tokyo Special Exhibit

[2013-06-13_0008] Network Topologies 1994-2013 Tokyo.

Another Task: Promotion Support

[2013-06-12_0041] Dispatched NOC members to a booth seminar of a ShowNet contirbutor, as one of their important missions during the show.
